QH-3000 Flexible Bending Center

QH-3000 Flexible Bending Center

Brand Name:	QIHAI
Model Number:	QH - 8025FD
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100 set/month

Detail Information

Product Description

Detail Information

Place of Origin:

Foshan, Guangdong, China

Certification:

ISO, CE

Graphic Format Supported:

DXF,AI,BMP,PLT,DWG

Cnc Or Not:

Yes

Cooling Mode:

Water Cooling

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Cooling System:

Water Cooling,CW5200 Waterchiller,Industry Water Chiller

Packaging Details:

wood, plastic

Highlight:

Automatic Flexible Bending Center

Sheet Metal Components Flexible Bending Center

Sheet Metal Components Automatic Bending Machine

Product Description

QH-3000 Flexible Bending Center

Description

The QH-3000 Flexible Bending Center is a high-performance intelligent bending equipment, with its core advantages focusing on a maximum bending length of 3000mm and a groundbreaking solution to the pain points of "slow changeover and mold dependence" through mold-free adaptive technology + minute-level quick changeover. Specifically designed for small-batch, multi-variety production scenarios such as brackets (special-shaped brackets), multi-angle shells, and precision sheet metal components, it breaks through the limitations of traditional bending machines that require custom molds and take hours to days for changeover—realizing mold-free direct bending and efficient, flexible processing, which is more economical and practical for small-batch, multi-variety production.

Its core selling points perfectly address industry pain points: unlike traditional bending machines that rely on custom molds for different workpieces, the QH-3000 adopts advanced mold-free adaptive technology, eliminating the need for preset molds and directly completing bending operations. With minute-level parameter adjustment, after importing the workpiece graphics, the machine automatically generates the bending path, compressing the changeover time from "hour-level" (traditional machines) to "minute-level", completely getting rid of mold dependence. Equipped with a maximum bending length of 3000mm, it can easily handle large-size sheet metal bending tasks, while supporting different bending thicknesses for various materials: 0.3-0.8mm for iron plates, 0.3-1.5mm for aluminum plates, and 0.3-0.6mm for stainless steel plates. It features a minimum bending size of 220mm, a bending height of 150mm (up to 250mm), a feeding step accuracy of ±0.1mm, and a maximum table moving speed of 32m/min, ensuring high-precision and high-efficiency bending.

Quick details

Core Highlights: Maximum bending length of 3000mm for large-size workpiece processing; solves "slow changeover and mold dependence" pain points via mold-free adaptive technology (no preset molds needed) + minute-level quick changeover (automatic bending path generation after graphic import), realizing mold-free direct bending.

Key Specifications: Maximum bending length 3000mm; bending thickness: 0.3-0.8mm (iron plate), 0.3-1.5mm (aluminum plate), 0.3-0.6mm (stainless steel plate); minimum bending size 220mm; bending height 150mm (250mm optional); feeding step accuracy ±0.1mm; maximum table moving speed 32m/min.

Basic Parameters: Power 60KW; voltage 380V/220V; machine weight 16T; overall dimension 450×380×280cm.

Application Scope: Small-batch, multi-variety production scenarios, such as special-shaped brackets, multi-angle shells, precision sheet metal components, requiring mold-free, quick-changeover and large-length bending.

Technical Specification

Bending Thickness of Iron Plate/	0.3-0.8mm
Bending Thickness of Aluminum Plate	0.3-1.5mm
Bending Thickness of Stainless Steel	0.3-0.6mm
Min Bending Size	220mm
Max Bending Length	3000mm
Bending Height	150(250)mm
Feeding Step Accuracy	±0.1mm
Maximum Moving Speed of Table	32m/min:
Voltage	380/220V
Power	60KW
Machine Weight	16T
Overall Dimension	450380280cm

Advantage

3000mm Maximum Bending Length Expands Processing Scope: With a maximum bending length of 3000mm, the QH-3000 can directly process large-size sheet metal workpieces in one pass, avoiding the inefficiency and precision loss caused by splicing small-length bending. This expands the application scope of the equipment, enabling it to meet the bending needs of large-size components in industries such as machinery, electronics and construction, and reducing processing steps and time.

Mold-Free Adaptive + Minute-Level Changeover Solves Core Pain Points: By adopting mold-free adaptive technology, the machine eliminates the need for custom molds, saving mold purchase, storage and maintenance costs. The minute-level quick changeover (automatic bending path generation after graphic import) compresses the changeover time from hours to days (traditional bending machines) to minutes, making small-batch, multi-variety production more economical and efficient, and solving the problem of high cost and low efficiency of traditional machines in small-batch production.

High Precision Ensures Consistent Bending Quality: Equipped with a feeding step accuracy of ±0.1mm and stable table movement (32m/min maximum speed), the QH-3000 ensures precise positioning and uniform bending force during the bending process. This avoids bending deviations and uneven angles, ensuring consistent quality of each workpiece, especially suitable for high-precision processing of complex components such as multi-angle shells and special-shaped brackets.

Versatile Material Compatibility Enhances Adaptability: The machine supports bending of three common materials (iron, aluminum, stainless steel) with different thickness ranges, covering most common sheet metal materials in industrial production. It does not require mold replacement for different materials or thicknesses, further improving changeover efficiency and operational convenience, and reducing equipment investment costs for enterprises.

Efficient and Intelligent Operation Reduces Cost and Improves Efficiency: The mold-free design and automatic path generation simplify the operation process, reducing the dependence on skilled operators and human errors. The high table moving speed (32m/min) and minute-level changeover significantly improve production efficiency, while the elimination of mold costs and reduced labor costs achieve comprehensive cost reduction. The equipment’s stable performance and industrial-grade configuration ensure long-term continuous operation, further enhancing production efficiency and creating long-term economic benefits.
