| Brand Name: | QIHAI |
| Model Number: | QH-GA |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 Set/month |
Core Smart Features: Automatic obstacle avoidance (real-time detects obstacles to stop/adjust, preventing equipment/tube damage); semi-automatic loading (reduces manual handling, cuts loading time by 40% vs. fully manual machines).
Key Specs: Φ15-500mm (round tube)/15×15-500×500mm (square tube), 5500-6500mm tube length, 1500W-20KW laser power, ±0.03mm accuracy, 1.7T weight, 8500×1380×2050mm dimensions.
Fit: Round/square tube processing; semi-automated workshops (steel structure/furniture/mechanical engineering) prioritizing safety and labor efficiency.
| Model | QH-GA-6012 |
|---|---|
| Cutting Diameter | Round Tube: Φ15-500mm Square Tube: 15*15mm to 500*500mm |
| Tube Length Capacity | 5500-6500mm |
| Machine Weight | 1.8T |
| Chuck installation on the lathe | Side-mounted |
| Dimensions (L*W*H) | 8500*2920*2050mm |
| Laser Power Range | 1500W-20KW |
| Positioning Accuracy | ±0.03mm (X/Y-axis) |
| Repositioning Accuracy | ±0.03mm (X/Y-axis) |
| Compatible Tube Types | Round Tube / Square Tube |
Automatic Obstacle Avoidance Enhances Safety & Reliability: The machine’s built-in obstacle avoidance system uses sensors to real-time detect irregularities on tube surfaces (e.g., dents, weld seams) or external obstacles (e.g., misaligned fixtures). It automatically pauses cutting or adjusts the path to avoid collisions, reducing the risk of equipment wear (e.g., laser head damage) and tube scrap—lowering maintenance costs by 25% vs. non-obstacle-avoidance models.
Semi-Automatic Loading Balances Efficiency & Cost: Unlike fully manual machines that require heavy manual lifting for tube positioning, its semi-automatic loading system assists with tube alignment and feeding (manual initiation, automated positioning). This cuts operator labor intensity by 30% and loading time by 40%, while avoiding the high cost of fully automatic loading/unloading systems—making it a cost-effective choice for medium-volume production.
Precision & Adaptability for Routine Tube Needs: Paired with ±0.03mm positioning/repositioning accuracy, the machine meets the precision requirements of standard tube applications (e.g., structural supports, furniture frames). It covers over 90% of common tube sizes (Φ15-500mm round, 15×15-500×500mm square) without specialized upgrades, ensuring consistent cut quality while leveraging smart features (obstacle avoidance, semi-automatic loading) to boost overall workflow efficiency.
