| Brand Name: | QIHAI |
| Model Number: | QH - 6015FB |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/month |
High-Speed Core (1.5G Acceleration): 1.5G maximum linkage acceleration cuts non-cutting time (traversal/start-stop) by 40% vs. 1.0G machines; paired with 100m/min speed for fast large-workpiece processing.
Key Specs: 6000×1500mm area (1000kg max loading), 1500W-20KW power (0.5-25mm thickness), ±0.03mm X/Y accuracy (maintained at high speed).
Dual-Platform & Enclosed Edge: Alternating dual platforms enable non-stop loading/unloading (boosting efficiency by 30%); enclosed structure ensures dust-proof, low-noise high-speed operation.
Fit: Construction machinery, large appliances; 380V/50Hz industrial compatibility.
| Processing Area | 6000 * 1500mm |
| Maximum Loading Weight | 1000kg |
| Machine Weight | 3500kg |
| Overall Dimensions | 8500×2280×2150mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.5G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
1.5G Acceleration + Dual Platforms = Uninterrupted High-Speed Production: The 1.5G acceleration minimizes time spent on workpiece positioning and path transitions, while dual alternating platforms allow one platform to process at high speed (100m/min) while the other loads/unloads. This eliminates downtime between batches—for example, processing 50pcs of 5m×1.2m steel plates takes 25% less time than single-platform machines, directly boosting daily output.
High Speed Without Precision Loss: Thanks to the double rack & pinion servo transmission, the machine retains ±0.03mm X/Y-axis accuracy even at 1.5G acceleration. Unlike low-stability high-speed cutters that produce burrs or misaligned cuts, it delivers smooth, consistent edges across large workpieces (e.g., 6m-long appliance panels), reducing post-processing needs and scrap rates by 25%-30%.
Enclosed Design Supports Stable High-Speed Longevity: The enclosed structure blocks workshop dust from entering the transmission system—critical for maintaining 1.5G acceleration’s stability over time. Its 3500kg heavy-duty frame absorbs vibration generated by high acceleration, preventing wear on gears and guides, which extends component lifespan by 40% compared to lightweight high-speed machines.
Large-Area High-Speed Versatility: The 6000×1500mm processing area lets the 1.5G acceleration shine on large workpieces (e.g., construction machinery frames) by cutting down traversal time across the entire platform. Combined with 1500W-20KW laser power, it handles thin (0.5mm aluminum) and thick (25mm carbon steel) materials at high speed, eliminating the need for separate machines for different workpiece sizes or thicknesses.
