QH-8025FB Sheet Metal Laser Cutting Machine Beveling Cutting, Dual Table 8000×2500mm

QH-8025FB Sheet Metal Laser Cutting Machine Beveling Cutting, Dual Table 8000×2500mm

Brand Name:	QIHAI
Model Number:	QH - 8025FB
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100 set/month

Detail Information

Product Description

Detail Information

Place of Origin:

Foshan, Guangdong, China

Certification:

ISO, CE

Graphic Format Supported:

DXF,AI,BMP,PLT,DWG

Cnc Or Not:

Yes

Cutting Thickness:

Materials,0-30mm,Depends,7-8,1-12 M (carbon Steel)

Cooling Mode:

Water Cooling

Warranty:

1 Year

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Cooling System:

Water Cooling,CW5200 Waterchiller,Industry Water Chiller

Graphic Format Supported:

DXF,AI,BMP,PLT,DWG

Cnc Or Not:

Yes

Cutting Thickness:

Materials,0-30mm,Depends,7-8,1-12 M (carbon Steel)

Cooling Mode:

Water Cooling

Warranty:

1 Year

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Cooling System:

Water Cooling,CW5200 Waterchiller,Industry Water Chiller

Packaging Details:

wood, plastic

Highlight:

fiber laser metal cutting machine with beveling

dual table sheet metal laser cutter

8000x2500mm laser cutting machine

Product Description

QH-8025FB Sheet Metal Laser Cutting Machine (Beveling Cutting, Dual Table 8000×2500mm)

Description

The QH-8025FB Sheet Metal Laser Cutting Machine is a high-performance, heavy-duty sheet processing equipment that takes the lead in the industry with two core advantages: 40kw laser power (as the first manufacturer in Foshan, China to launch a 40kw laser cutting machine) and Beveling Cutting capability, paired with a 8000×2500mm dual-table design to achieve efficient, precise and versatile sheet metal processing. Designed for large-scale and high-demand industrial scenarios such as heavy machinery manufacturing, shipbuilding, and large-scale structural parts processing, this machine integrates powerful cutting performance, flexible bevel processing and intelligent dual-table operation to break through the limitations of traditional laser cutting equipment.

With an industry-leading 40kw laser power, it can easily cut thick and high-hardness sheet metals, ensuring fast cutting speed and smooth cutting edges without secondary processing. Its professional Beveling Cutting function supports precise bevel processing of various angles, meeting the welding and assembly needs of complex structural parts, which greatly reduces the subsequent processing steps and improves production efficiency. Equipped with an 8000×2500mm large-size dual table, the machine enables alternate loading and unloading, realizing non-stop production; the dual table design also effectively bears the maximum loading weight of 12000kg, adapting to the processing needs of large and heavy sheet metals.

Quick details

Core Highlights: 40kw laser power (the first manufacturer in Foshan, China to launch 40kw laser cutting machine); professional Beveling Cutting function; 8000×2500mm dual table.

Key Specifications: 8000×2500mm processing area; 12000kg maximum loading weight; ±0.03mm X/Y-axis positioning and repositioning accuracy; 100m/min maximum linkage speed; 1.0G maximum linkage acceleration.

Structural Features: 10000kg machine weight; 19680×3958×2560mm overall dimensions; double rack & pinion transmission with servo drive; 380V/50Hz voltage and frequency requirement.

Application Scenarios: Heavy machinery manufacturing, shipbuilding, large-scale structural parts processing, thick sheet metal processing that requires bevel welding.

Technical Specifications

Processing Area	8000 * 2500mm
Maximum Loading Weight	12T
Machine Weight	15T
Overall Dimensions	19680×3958×2560mm
Laser Power Range	40KW
X/Y-axis Positioning Accuracy	±0.03mm
X/Y-axis Repositioning Accuracy	±0.03mm
Maximum Linkage Acceleration	1.0G
Maximum Linkage Speed	100m/min
Transmission System	Double rack & pinion transmission with servo drive
Voltage Requirement	380V
Frequency	50Hz
Beveling Cutting	±45°

QH-8025FB Sheet Metal Laser Cutting Machine Beveling Cutting, Dual Table 8000×2500mm 0

Advantage

Leading 40kw Laser Power (First in Foshan): As the first manufacturer in Foshan, China to launch a 40kw laser cutting machine, the QH-8025FB has unparalleled cutting power compared to conventional low-power equipment. It can efficiently cut thick sheet metals (up to 50mm thick carbon steel) with 30% faster cutting speed than 30kw laser cutting machines, while ensuring smooth, burr-free cutting edges that reduce secondary grinding workload. The 40kw high power also enhances the cutting capability of high-hardness materials (such as stainless steel and alloy steel), expanding the application scope of the machine and meeting the diverse needs of heavy industry.

Precise and Efficient Beveling Cutting: The integrated Beveling Cutting function eliminates the need for separate beveling equipment, realizing one-stop cutting and beveling processing. It can complete precise bevel cutting of 0-45° angles, with high bevel accuracy and uniform surface finish, which directly improves the welding quality and efficiency of subsequent processes. Compared with traditional manual or semi-automatic beveling methods, this function reduces labor costs by 60% and avoids errors caused by manual operation, ensuring consistent processing quality of each workpiece.

Synergy of 40kw Power and Beveling Cutting: The 40kw high laser power provides strong support for Beveling Cutting, especially for thick sheet metal bevel processing. It can quickly and stably cut bevels of different angles without insufficient power or uneven cutting, which solves the problem that low-power laser cutting machines cannot complete thick sheet metal bevel processing or have low processing efficiency. This synergy makes the machine suitable for complex structural parts that require both thick sheet cutting and precise beveling, enhancing its market competitiveness.

Dual Table Design Boosts Production Efficiency: The 8000×2500mm large dual table allows for alternate loading and unloading—while one table is in cutting operation, the other can complete workpiece loading and unloading, realizing non-stop production and reducing downtime by 50%. The dual table can also bear a maximum loading weight of 12000kg, adapting to the processing needs of large and heavy sheet metals, avoiding the trouble of frequent workpiece replacement and improving batch processing efficiency.

High Precision and Stability: Adopting double rack & pinion transmission with servo drive, combined with ±0.03mm high positioning and repositioning accuracy, the machine ensures precise cutting and beveling even during high-speed operation (100m/min maximum linkage speed). The 10000kg heavy-duty frame and stable structure effectively reduce vibration during operation, avoiding precision errors caused by machine shaking, and ensuring long-term stable processing quality, which is crucial for high-precision structural parts processing.
