| Brand Name: | Qihai |
| Model Number: | QH-6024GB |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 30 Set per Month |
The QH-6024GB combines a 240mm large chuck with a heavy-duty 3000W–20000W fiber laser and a bevel cutting module. It is built for fabricators who cut large-diameter, heavy-wall metal tube and need weld-ready edges straight off the machine.
The 240mm chuck accepts round tubes up to Φ240mm and square tubes up to 240 × 240mm, making it suitable for heavy structural and large-diameter tube. With up to 20000W of laser power, the machine maintains speed and edge quality even on thick-wall carbon steel, stainless steel and aluminum tube.
The bevel cutting module produces controlled angular cuts of up to ±45 degrees, forming V-bevels and compound bevels in the same clamping cycle as the straight cut. This removes a separate edge-preparation step and produces cleaner, tighter welds — a major advantage for heavy fabrication where joint quality is critical.
| Model | QH-6024GB |
| Tube Length | 6m |
| Chuck Diameter | 240mm |
| Large Chuck Diameter | 240mm |
| Round Tube Range | Φ10mm - Φ240mm |
| Square Tube Range | 10 × 10mm - 240 × 240mm |
| Laser Source Power | 3000W - 20000W |
| Cutting Thickness | 5-12mm |
| X/Y Positioning Accuracy | ±0.03mm |
| Control System | BOCHU |
| Cooling Mode | Water Cooling |
For a customized configuration or quotation, please contact us.
