| Brand Name: | QiHai |
| Model Number: | 6060J |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/month |
High-Accuracy Core: ±0.03mm X/Y-axis positioning & repositioning accuracy; screw guideway transmission minimizes vibration, ensuring consistent precision even for micro-sized cuts.
Key Specs: 600×600mm processing area (ideal for small precision parts), 60kg max loading, 1500W/3000W laser power, 40m/min linkage speed.
Fit: Precision-focused industries (electronics, medical); compact 1770×1650×1800mm size suits lab-like or small workshop environments.
| Specification | Value |
|---|---|
| Processing Area | 600 * 600mm |
| Maximum Loading Weight | 60kg |
| Machine Weight | 1200kg |
| Overall Dimensions | 1770 * 1650 * 1800mm |
| Laser Power Range | 1500W/3000W |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 0.8G |
| Maximum Linkage Speed | 40m/min |
| Transmission System | Screw guideway transmission |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Superior Precision for Micro-Cutting Tasks: The ±0.03mm dual-axis accuracy (positioning & repositioning) paired with screw guideway transmission—known for low backlash and high stability—enables the machine to cut micro-features (e.g., 0.5mm-diameter holes, 0.2mm-wide slots) with minimal deviation. This meets strict tolerance requirements of precision components, eliminating the need for post-cut calibration and reducing scrap rates by 20%-30%.
Stable Precision Across Materials: Unlike machines with rack-and-pinion systems that may fluctuate in precision when cutting thin or soft materials, the screw guideway transmission of the QH-6060J maintains consistent pressure and movement control. Whether processing 0.1mm thin stainless steel sheets or 10mm aluminum parts, it retains ±0.03mm accuracy, ensuring uniform quality across different workpiece types.
Compact Design Without Precision Compromise: Despite its space-saving 1770×1650×1800mm footprint (suitable for small precision workshops or lab settings), the machine doesn’t sacrifice accuracy. Its 1200kg sturdy frame reduces external vibration interference, while the dedicated screw guideway structure prioritizes precision over high-speed bulk processing—making it a cost-effective yet reliable solution for businesses focused on high-tolerance small-part manufacturing.
