| Brand Name: | QIHAI |
| Model Number: | QH-6020F |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/month |
High Speed Core: 100m/min maximum linkage speed + 1.5G acceleration (30%-40% faster than standard laser cutters); double rack & pinion servo transmission maintains ±0.03mm axis accuracy at high speeds.
Key Specs: 6000×2000mm processing area (1000kg max loading), 1500W-20KW laser power (0.5-25mm material thickness), 380V/50Hz industrial power compatibility.
Fit: Automotive/home appliance large-batch production; cuts thin-thick materials fast without precision loss.
| Processing Area | 6000 * 2000mm |
| Maximum Loading Weight | 1000kg |
| Machine Weight | 3600kg |
| Overall Dimensions | 8000×2760×1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.5G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
Dramatic Throughput Improvement: The 100m/min linkage speed and 1.5G acceleration slash processing time for high-volume orders—for example, cutting 100 sets of 6m×2m automotive chassis components takes 25%-35% less time than machines with 60-80m/min speed. Rapid workpiece positioning also reduces idle time between cuts, boosting daily output by 40%-50% for continuous production lines.
High-Speed Precision Stability: Unlike budget high-speed cutters that suffer accuracy drift (e.g., ±0.05mm+ deviation) at max speed, the QH-6020F’s double rack & pinion servo system ensures tight ±0.03mm precision even during 100m/min traversal. This eliminates secondary trimming or calibration, saving post-processing time and reducing scrap rates by 20%-25%—critical for precision-dependent parts like automotive brackets.
Speed Adaptability Across Materials: The 1500W-20KW power range lets it maintain fast cutting across thicknesses: 1500W cuts 0.5-3mm stainless steel at 85-95m/min (ideal for thin appliance parts), while 20KW handles 20-25mm carbon steel at 12-15m/min (3x faster than low-power machines for thick sheets). This versatility means one machine can handle mixed-thickness batches without speed or quality trade-offs.
Industrial-Grade High-Speed Durability: The 3600kg heavy-duty frame absorbs vibration from 1.5G acceleration, preventing mechanical wear that shortens the lifespan of lighter high-speed machines. A dedicated high-efficiency cooling system (paired with servo components) ensures stable operation even during 24/7 high-speed runs—avoiding overheating-related downtime that plagues less robust cutters in large-batch scenarios.
