| Brand Name: | QiHai |
| Model Number: | QH-4015F |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 90set/mon |
High-Speed Core (1.5G Acceleration): 1.5G maximum linkage acceleration cuts non-cutting time (start/stop, traversal) by 40% vs. 1.0G machines; paired with 100m/min speed for fast batch processing.
Key Specs: 4000×1500mm area (900kg max loading), 1500W-20KW power (0.5-25mm thickness), ±0.03mm X/Y accuracy (maintained at high speed).
Efficiency: 1.5G acceleration + double rack & pinion drive slashes batch cycle time by 30%-35% for high-volume tasks.
Fit: Automotive components, hardware bulk production; 380V/50Hz industrial compatibility.
| Processing Area | 4000 * 1500mm |
| Maximum Loading Weight | 900kg |
| Machine Weight | 1700kg |
| Overall Dimensions | 5500 * 2350 * 1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.0G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
1.5G Acceleration Drives Unmatched Batch Efficiency: The 1.5G maximum linkage acceleration enables the machine to rapidly accelerate/decelerate between cutting segments—for example, reducing traversal time across the 4000×1500mm area by 40% compared to 1.0G accelerators. When processing batches of small-to-medium parts (e.g., 500pcs of 200×150mm hardware components), this cuts total cycle time by 30%-35%, directly boosting daily output without extending working hours.
High Speed Without Precision Compromise: Unlike low-acceleration machines that trade speed for accuracy, the QH-4015F’s double rack & pinion transmission with servo drive stabilizes motion even at 1.5G, retaining ±0.03mm X/Y-axis positioning and repositioning accuracy. This ensures consistent cut quality (smooth edges, no burrs) for high-speed batch jobs—eliminating the need for post-processing and reducing scrap rates by 25%-30%.
Adaptable High-Speed Processing for Diverse Workpieces: With a 4000×1500mm processing area and 900kg maximum loading weight, the machine’s 1.5G acceleration isn’t limited to small parts—it efficiently handles medium-large workpieces (e.g., 3.5m×1.2m automotive chassis panels) by minimizing time spent on positioning and path transitions. The 1500W-20KW laser power range further supports this versatility, cutting thin (0.5mm aluminum) and thick (25mm carbon steel) materials at high speed.
Stable High-Speed Operation for Longevity: Its 1700kg sturdy frame absorbs vibration generated by 1.5G acceleration, preventing wear on transmission components and extending machine lifespan. The 380V/50Hz standard power supply ensures consistent energy input for stable high-speed performance, avoiding speed fluctuations that could disrupt batch processing—making it a reliable choice for continuous industrial production shifts.
