QH-8025FD High power Large format Sheet Metal Laser Cutting Machine 8000×2500mm

QH-8025FD High power Large format Sheet Metal Laser Cutting Machine 8000×2500mm

Brand Name:	QIHAI
Model Number:	QH - 8025FD
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100 set/month

Detail Information

Product Description

Detail Information

Place of Origin:

Foshan, Guangdong, China

Certification:

ISO, CE

Graphic Format Supported:

DXF,AI,BMP,PLT,DWG

Cnc Or Not:

Yes

Cutting Thickness:

Materials,0-30mm,Depends,7-8,1-12 M (carbon Steel)

Cooling Mode:

Water Cooling

Warranty:

1 Year

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Cooling System:

Water Cooling,CW5200 Waterchiller,Industry Water Chiller

Packaging Details:

wood, plastic

Highlight:

8000x2500mm large format laser cutter

high power sheet metal cutting machine

fiber laser metal cutter with warranty

Product Description

QH-8025FD High power Large format Sheet Metal Laser Cutting Machine 8000×2500mm

Description

The QH-8025FD is a high-precision, heavy-duty sheet metal processing equipment specially engineered for Large-format sheet processing, with its 8000×2500mm ultra-large processing area as the core highlight, complemented by stable performance and intelligent design to meet the efficient cutting needs of large-size, heavy-weight sheet metals in industrial scenarios. Designed for large-scale structural parts manufacturing, construction machinery, shipbuilding, and large-panel processing industries, this machine breaks through the limitations of small and medium-format laser cutting equipment, integrating large-format compatibility, high precision, and efficient operation into one, providing a comprehensive solution for large-size sheet metal processing.

Its 8000×2500mm large-format processing area allows for one-time cutting of extra-large sheet metals without secondary splicing, which not only improves processing efficiency but also avoids precision errors caused by splicing, ensuring the integrity and consistency of large workpieces.

Quick details

The QH-8025FD is a professional sheet metal laser cutting machine that takes High power as its core advantage and integrates an 8000×2500mm large format processing area, designed to provide efficient, precise and stable cutting solutions for large-size, thick-gauge sheet metal processing scenarios. Specifically tailored for industries demanding high-power and large-format cutting—such as large-scale structural parts manufacturing, heavy machinery production, high-strength steel plate processing, and large-batch large-size sheet metal fabrication—this machine breaks through the performance bottlenecks of conventional laser equipment, combining ultra-high laser power, large-format compatibility and high-precision transmission to meet the rigorous requirements of high-intensity, large-size industrial processing.

Technical Specifications

Processing Area	8000 * 2500mm
Maximum Loading Weight	12T
Machine Weight	15T
Overall Dimensions	19680×3958×2560mm
Laser Power Range	1500W - 20KW
X/Y-axis Positioning Accuracy	±0.03mm
X/Y-axis Repositioning Accuracy	±0.03mm
Maximum Linkage Acceleration	1.0G
Maximum Linkage Speed	100m/min
Transmission System	Double rack & pinion transmission with servo drive
Voltage Requirement	380V
Frequency	50Hz
Beveling Cutting	±45

QH-8025FD High power Large format Sheet Metal Laser Cutting Machine 8000×2500mm 0

Advantage

High Power Breaks Through Thick-Sheet & Large-Format Cutting Limitations: Compared with low-power laser cutting machines, the 6000W-20KW high-power laser of QH-8025FD can easily cut extra-thick sheet metals (up to dozens of millimeters thick) and high-hardness, high-strength materials that are difficult to process by low-power equipment. Combined with the 8000×2500mm large format, it realizes one-time cutting of large-size sheets, avoiding the trouble of splicing and improving processing efficiency and overall workpiece precision. The high power also ensures fast cutting speed (up to 100m/min linkage speed) while maintaining smooth edges, reducing processing time and secondary finishing costs.

High Power with High Precision & Cost-Efficiency: The machine’s ±0.03mm positioning and repositioning accuracy, paired with the 6000W-20KW adjustable high-power range, enables flexible adaptation to different processing needs—from thin large-size sheets to extra-thick plates, from ordinary steel to high-strength alloys—without the need for multiple devices. The 12000kg maximum loading weight allows it to handle heavy large-format sheets, reducing equipment investment costs for enterprises. Meanwhile, the high-power laser’s optimized energy efficiency reduces energy consumption per unit of processing, and the stable structure minimizes maintenance frequency, lowering long-term operation costs.

High Power Boosts Production Efficiency for Large-Batch Work: The synergy between high power (fast cutting speed) and large format (one-time processing of large sheets) greatly improves production efficiency. For large-batch large-size sheet metal orders, the QH-8025FD can complete more workpieces in the same time compared with low-power or small-format machines. The 100m/min maximum linkage speed, combined with the high-power laser’s fast cutting capability, shortens the processing cycle of each workpiece, while the large format reduces the number of clamping times, further improving overall production efficiency and meeting the demand for large-batch, high-speed processing.
