| Brand Name: | QIHAI |
| Model Number: | QH-3015R |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/month |
High-Speed Core: 100m/min maximum linkage speed + 1.5G acceleration (double rack & pinion servo drive ensures stable high-speed motion).
Precision at Speed: ±0.03mm X/Y-axis positioning/repositioning accuracy, avoiding burrs or deviations even during rapid cutting.
Power Adaptability: 1500W-20KW laser range handles 0.5-25mm metals (carbon steel, stainless steel, aluminum) without speed compromises.
Practical Build: 3000×1500mm area + 500kg loading; 7700×2765×1980mm dimensions fit standard factories; 1600kg frame resists high-speed vibration.
| Specification | Value |
|---|---|
| Processing Area | 3000 × 1500mm |
| Maximum Loading Weight | 500kg |
| Machine Weight | 1600kg |
| Overall Dimensions | 7700×2765×1980mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.5G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
Unmatched Production Efficiency: With 100m/min linkage speed and 1.0G acceleration, it cuts coil processing cycles by 40%-50% compared to traditional coil cutters. This high throughput eliminates bottlenecks in mass production, enabling faster delivery for high-volume orders (e.g., automotive component batches).
Precision Retention at High Speed: The double rack & pinion servo transmission works with ±0.03mm dual-axis accuracy to prevent speed-induced deviations. This means no secondary trimming is needed, reducing material waste by 15%-20% and ensuring consistent part quality—critical for industries with strict tolerance requirements.
Versatile High-Speed Operation: The 1500W-20KW laser power range allows it to maintain high speed across thin (0.5mm) to thick (25mm) metals, avoiding the need to switch machines for different materials. Combined with 500kg loading capacity, it adapts to diverse coil sizes, making it a one-stop solution for multi-product lines while retaining rapid processing capabilities.
