| Brand Name: | QIHAI |
| Model Number: | QH-6020L |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 set/month |
Auto Material-Lifting Core: Integrated support system reduces manual material handling; fits 1000kg heavy/oversized sheets (6000×2000mm area) for labor-saving operation.
Precision & Speed: ±0.03mm dual-axis accuracy + 100m/min linkage speed (1.0G acceleration) ensures fast, burr-free cuts.
Power & Adaptability: 1500W-20KW laser handles diverse metals; 380V/50Hz compatibility fits factory setups.
Sturdy Build: 3600kg weight + double rack & pinion transmission resists vibration during high-speed/large-load processing.
| Processing Area | 6000 * 2000mm |
| Maximum Loading Weight | 1000kg |
| Machine Weight | 3600kg |
| Overall Dimensions | 8000×2760×1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.0G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
Labor-Saving & Material-Protective Auto Lifting: The automatic material-lifting support system eliminates manual lifting of 1000kg heavy sheets, cutting labor costs by 30%-40% and reducing material scratches from manual handling. It also enables smooth loading/unloading for 6000×2000mm oversized sheets, avoiding deformation that often occurs with manual movement—critical for maintaining part integrity.
Large-Format Processing with High Precision: Its 6000×2000mm processing area eliminates the need for splicing small sheets when manufacturing large components (e.g., machinery casings, ship parts), while ±0.03mm positioning accuracy ensures consistent quality across the entire large workpiece. Paired with 100m/min speed, it boosts efficiency for large-batch, big-size production.
Stable Performance for Heavy-Duty Use: The 3600kg robust frame and double rack & pinion servo transmission minimize vibration during high-speed (100m/min) or heavy-load (1000kg) operation, ensuring long-term cutting stability. The 1500W-20KW laser power range further allows it to process thin (0.5mm) to thick (25mm) metals without compromising speed, making it a versatile, reliable choice for heavy-industry applications.
