| Brand Name: | QiHai |
| Model Number: | QH-3015F |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 90set/mon |
Core Selling Point: Economical best-seller with high cost-performance; user-friendly operation, fits multiple workshop spaces.
Key Specs: 3000×1500mm processing area, 800kg max loading; 3000W laser (1500W-20KW range), ±0.03mm precision.
Efficiency & Adaptability: 100m/min max speed, 1.0G acceleration; 4800×2350×1900mm compact size; 380V/50Hz universal power.
| Processing Area | 3000 * 1500mm |
| Maximum Loading Weight | 800kg |
| Machine Weight | 1600kg |
| Overall Dimensions | 4800 * 2350 * 1900mm |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.0G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
High-Speed & High-Precision Processing: Adopting a dual-drive gantry structure , imported precision transmission components, and an independent numerical control system , it achieves a cutting speed of up to 40 m/min for 1mm stainless steel and 85-100 m/min for 0.5mm stainless steel.
Economical & Energy-Saving Performance: With a photoelectric conversion efficiency of 70%-80% , its power consumption is only 20%-30% of traditional CO₂ equipment.
Strong Adaptability: Boasting a standard processing area of 3000×1500mm, it can cut carbon steel, stainless steel, aluminum, copper (highly reflective materials ), titanium alloy, and other special metals, with a thickness range of 0.5mm to 25mm (depending on power configuration).
Low-Consumption & Maintenance-Free Design: Fiber optic transmission eliminates the need for optical path adjustment and reflective lens replacement.
