| Brand Name: | QIHAI |
| Model Number: | QH-3015FT |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 90set/mon |
| Processing Area | 3000 * 1500mm |
| Maximum Loading Weight | 800kg |
| Machine Weight | 2500kg |
| Overall Dimensions | 8450×3250×1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.0G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
The QH-3015FT/6012 combines sheet and tube laser cutting in one machine, reducing the need for separate equipment while maintaining high cutting precision and stable operation. The double rack & pinion transmission with servo drive provides responsive and accurate movement, while the ±0.03 mm positioning and repositioning accuracy supports consistent cutting quality. With speeds up to 100 m/min and acceleration up to 1.0 G, the machine achieves high processing efficiency. In addition, the bevel cutting function allows the cutting head to process angled edges, expanding its capability for structural parts, fabrication, and applications requiring high-precision bevel cuts.
