| Brand Name: | QIHAI |
| Model Number: | QH-GA |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 Set/month |
Triple Core Features: Semi-automatic loading (assists 5500-6500mm tube feeding, retains operator control); weldseam identification (real-time weld detection, maintains ±0.03mm accuracy); automatic obstacle avoidance (0.1s hazard response, collision prevention).
Key Specs: Model QH-GA-6012; cuts Φ15-500mm round/15×15-500×500mm square tubes; 1500W-20KW laser power; 1.8T weight; 8500×2920×2050mm dimensions.
Fit: Medium-batch long-tube processing (construction/automotive); flexible for mixed tube specs, safe & precise.
| Model | QH-GA-6012 |
|---|---|
| Cutting Diameter | Round Tube: Φ15-500mm Square Tube: 15*15mm to 500*500mm |
| Tube Length Capacity | 5500-6500mm |
| Machine Weight | 1.8T |
| Chuck installation on the lathe | Side-mounted |
| Dimensions (L*W*H) | 8500*2920*2050mm |
| Laser Power Range | 1500W-20KW |
| Positioning Accuracy | ±0.03mm (X/Y-axis) |
| Repositioning Accuracy | ±0.03mm (X/Y-axis) |
| Compatible Tube Types | Round Tube / Square Tube |
Semi-automatic Loading = Flexibility + Labor Savings: Unlike fully manual setups (high labor intensity) or fully automatic systems (rigid for small/batch changes), the semi-auto loading assists with heavy 5500-6500mm tube positioning (cutting manual effort by 50%) while letting operators adjust for mixed specs (e.g., switching from Φ100mm to Φ300mm round tubes in 5 minutes). This makes it ideal for workshops with diverse orders, boosting batch adaptability by 40% vs. fully auto models.
Weldseam Identification + ±0.03mm Precision = No Rework: The real-time weld detection eliminates uneven cuts caused by unaddressed welds (a common issue with standard cutters). By adjusting cutting speed/power at weld zones, it ensures uniform edge quality across the entire tube length—reducing rework rates by 50% for welded tubes (e.g., construction truss tubes) and meeting high-tolerance demands for automotive subframes.
Automatic Obstacle Avoidance + Horizontal Lathe = Safety + Stability: The 0.1s fast-response avoidance system protects the laser head (costly to repair) from misfed tubes or debris, cutting equipment downtime by 60% vs. non-avoidance models. Paired with the horizontal lathe’s side-mounted chuck (which prevents 6500mm tube sagging), this combo ensures consistent cutting accuracy even during long shifts—critical for maintaining batch quality and extending machine lifespan.
