| Brand Name: | QIHAI |
| Model Number: | QH-3015F |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 90set/mon |
High Speed Core: 1.5G maximum linkage acceleration for fast start-stop/trajectory switching; cuts non-cutting time by 40%-50% vs. 1.0G machines; paired with 100m/min linkage speed.
Key Specs: 3000×1500mm area (800kg max loading), ±0.03mm X/Y accuracy (stable at high acceleration), 1500W-20KW power (thin-thick metal adaptability), double rack & pinion servo transmission.
Fit: Batch production (hardware/electronics), complex-pattern cutting; 380V/50Hz industrial compatibility.
| Processing Area | 3000 * 1500mm |
| Maximum Loading Weight | 800kg |
| Machine Weight | 1600kg |
| Overall Dimensions | 4800 * 2350 * 1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.5G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
Advantage
1.5G Acceleration Slashes Overall Processing Time: For complex workpieces (e.g., 3000×1500mm sheets with 50+ cut holes), the 1.5G acceleration reduces time spent on moving between cut paths by 40%-50% compared to standard 1.0G machines. For example, a batch of 100 electronic enclosures (with multiple small cutouts) is completed in 1.5 hours vs. 2.5 hours with lower-acceleration models—directly boosting daily production capacity.
High Speed + Precision Coexistence: The double rack & pinion servo transmission and 1600kg sturdy frame eliminate "shake" during 1.5G acceleration/deceleration, ensuring ±0.03mm axis accuracy is maintained even when switching between tight cut paths. This avoids the common trade-off between speed and precision, making the machine suitable for high-speed cutting of precision parts (e.g., hardware hinges with tight tolerance requirements).
Adaptable to Batch & Complex Workloads: The 1.5G acceleration excels in two key scenarios: batch processing (fast reset between identical workpieces) and complex patterns (rapid traversal between disjoint cut paths). Combined with the 3000×1500mm area and 800kg loading capacity, it handles both small-batch high-precision parts and medium-batch standard sheets—reducing the need for multiple machines for different production needs.
Energy-Efficient High-Speed Operation: Unlike high-speed machines that sacrifice energy efficiency, the QH-3015F’s 1.5G acceleration is optimized for short burst movements (typical in cutting tasks), minimizing unnecessary power consumption. Its 380V/50Hz power configuration aligns with standard industrial grids, and the double rack & pinion system requires minimal maintenance—lowering long-term operational costs while retaining high-speed performance.
