| Brand Name: | QIHAI |
| Model Number: | QH-3015F-BG |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 Set/month |
±45° Bevel Core: 0.1° adjustable increments, ±0.5° angle accuracy; supports V/U/Y bevels—eliminates secondary processing, cuts weld prep time by 40%.
Key Specs: 3000×1500mm area (800kg max loading), ±0.03mm axis precision (bevel consistency), 1500W-20KW power (0.5-25mm bevel thickness), 100m/min speed.
Semi-Enclosed Value: Shields sparks/fumes during beveling; easy access for large beveled workpieces.
Fit: Weld prefabrication (automotive/engineering machinery); 380V/50Hz industrial use.
| Processing Area | 3000 * 1500mm |
| Maximum Loading Weight | 800kg |
| Machine Weight | 1600kg |
| Overall Dimensions | 4800 * 2350 * 1900mm |
| Laser Power Range | 1500W - 20KW |
| X/Y-axis Positioning Accuracy | ±0.03mm |
| X/Y-axis Repositioning Accuracy | ±0.03mm |
| Maximum Linkage Acceleration | 1.0G |
| Maximum Linkage Speed | 100m/min |
| Transmission System | Double rack & pinion transmission with servo drive |
| Voltage Requirement | 380V |
| Frequency | 50Hz |
±45° Bevel Flexibility Covers Diverse Weld Needs: The full ±45° angle range adapts to varied weld joint requirements—from shallow 10° bevels for thin-sheet lap welding to steep 45° bevels for thick-plate butt welding. This eliminates the need for multiple bevel tools/machines, reducing equipment costs while ensuring consistent angle quality across different workpiece thicknesses (0.5-25mm).
High Precision Ensures Bevel Weld Compatibility: ±0.03mm X/Y-axis accuracy (powered by double rack & pinion transmission) guarantees uniform bevel depth and edge straightness—critical for weld joint fit-up. For example, 3m-long steel plates with ±45° bevels maintain <0.1mm angle deviation across the entire length, reducing weld gaps and rework rates by 35%-50% compared to less precise bevel machines.
Semi-Enclosed Design Optimizes Bevel Work Environment: Unlike open machines, the semi-enclosed structure contains sparks and metal dust generated during high-speed ±45° beveling, protecting the double rack & pinion system (extending its lifespan by 25%) and creating a safer workspace. It also retains easy side access to load/unload 3m-long beveled workpieces, avoiding delays from cumbersome enclosed-door operations.
