| Brand Name: | QIHAI |
| Model Number: | QH-GZ |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 Set/month |
Triple Core Advantages: 1.5G max linkage acceleration (high-speed processing); 6000W-20KW power (25mm thick-walled tube cuts); Zero-tailing (≤5mm residual, low scrap).
Key Specs: Φ15-500mm round/15×15-500×500mm square tubes; 5500-6500mm tube length; ±0.03mm X/Y precision.
Fit: Automotive/hydraulic industries; 2T weight + 9620×2950×2080mm size suits medium workshops.
| Model | QH-GZ |
|---|---|
| Cutting Diameter | Round Tube: Φ15-500mm Square Tube: 15*15mm to 500*500mm |
| Tube Length Capacity | 5500-6500mm |
| Machine Weight | 2T |
| Dimensions (L*W*H) | 9620*2950*2080mm |
| Laser Power Range | 1500W-20KW |
| Positioning Accuracy | ±0.03mm (X/Y-axis) |
| Repositioning Accuracy | ±0.03mm (X/Y-axis) |
| Compatible Tube Types | Round Tube / Square Tube |
| Maximum Cutting Speed | 1.5g |
1.5G High Speed Cuts Batch Processing Time: The machine’s 1.5G maximum linkage acceleration enables fast tube feeding, positioning, and cutting—for example, processing 100 6000mm-long round tubes (Φ200mm, 10mm wall) takes 2-2.5 hours, 30%-40% faster than standard tube cutters (3.5-4 hours). This directly boosts daily throughput for high-volume production lines.
High Power + Zero-tailing = Efficiency & Cost Savings: The 6000W-20KW power ensures one-pass cuts for 25mm thick-walled tubes (no time-consuming re-cuts), while Zero-tailing limits scrap to ≤5mm per tube. For a workshop processing 200 stainless steel tubes (Φ300mm, 6500mm long) monthly, this saves ~200kg of material annually—reducing raw material costs by 9%-13% while maintaining high-speed output.
High Speed Doesn’t Compromise Precision: Unlike low-precision high-speed cutters, the QH-GZ retains ±0.03mm X/Y accuracy even at maximum acceleration. This ensures uniform cut edges (no jaggedness or wall unevenness) for hydraulic or structural tubes, where poor quality causes leaks or load failures—cutting post-processing (grinding, calibration) by 55%-65% and lowering rework rates.
Multi-Tube Type Compatibility with Core Advantages: The machine delivers 1.5G speed, 6000W-20KW power, and Zero-tailing efficiency across both round (Φ15-500mm) and square (15×15-500×500mm) tubes. This eliminates the need for separate machines for different tube shapes, while the 5500-6500mm length capacity covers most industrial needs—maximizing equipment utility and reducing upfront investment.
