| Brand Name: | QIHAI |
| Model Number: | QH-GA |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 100 Set/month |
Dual Core Highlights: 1.5g maximum linkage acceleration (cuts tube processing cycle time by 35% vs. standard machines); semi-automatic loading (manual tube placement + auto-alignment, balances flexibility and labor efficiency).
Key Specs: QH-GA-6012; side-mounted chuck; cuts Φ15-500mm round/15×15-500×500mm square tubes (5500-6500mm length); ±0.03mm precision; 1500W-20KW laser power.
Safety & Fit: Automatic obstacle avoidance (protects high-speed operation); suited for medium-batch, multi-type tube tasks (no complex full-auto setup needed).
| Model | QH-GA-6012 |
|---|---|
| Cutting Diameter | Round Tube: Φ15-500mm Square Tube: 15*15mm to 500*500mm |
| Tube Length Capacity | 5500-6500mm |
| Machine Weight | 1.8T |
| Chuck installation on the lathe | Side-mounted |
| Dimensions (L*W*H) | 8500*2920*2050mm |
| Laser Power Range | 1500W-20KW |
| Positioning Accuracy | ±0.03mm (X/Y-axis) |
| Repositioning Accuracy | ±0.03mm (X/Y-axis) |
| Compatible Tube Types | Round Tube / Square Tube |
| Maximum Cutting Speed | 1.5G |
1.5g Acceleration Boosts Processing Efficiency: The 1.5g maximum linkage acceleration enables fast laser head traversal and cutting—for example, completing a full cut on a 6500mm-long Φ100mm round tube in 8-10 minutes (vs. 12-15 minutes with 0.8g standard machines). This high-speed performance reduces batch processing time by 30%-40%, critical for meeting tight production deadlines in medium-batch manufacturing.
Semi-Automatic Loading Adapts to High-Speed Workflows: Unlike fully automatic systems that require time-consuming material rack calibration for small batches, semi-automatic loading lets operators quickly switch between custom tube sizes (e.g., non-standard 5500mm square tubes) with <5 minutes of setup. The auto-alignment function ensures this flexibility doesn’t compromise speed—tubes are positioned accurately in seconds, keeping pace with the machine’s 1.5g acceleration.
High Speed + Precision = Consistent Quality: Even at 1.5g acceleration, the machine retains ±0.03mm X/Y-axis accuracy (paired with the side-mounted chuck’s stable clamping), avoiding “overshoot” errors common in low-precision high-speed cutters. This ensures clean, burr-free cuts on both thin (0.5mm aluminum) and thick (20mm carbon steel) tubes, reducing scrap rates by 25% vs. high-speed machines with lower precision.
Cost-Effective High-Speed Solution: Semi-automatic loading eliminates the high upfront cost of fully automatic material handling systems, making high-speed tube cutting accessible for small-to-medium workshops. Meanwhile, 1.5g acceleration and 1500W-20KW power retain industrial-grade efficiency—processing up to 150 tubes per shift (5500mm length) without sacrificing quality, delivering a better cost-performance ratio than over-equipped full-auto high-speed machines.
