QH - Vibration Bowl Automatic Feeder

QH - Vibration Bowl Automatic Feeder

Brand Name:	QIHAI
Model Number:	QH - 8025FD
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100 set/month

Detail Information

Product Description

Detail Information

Place of Origin:

Foshan, Guangdong, China

Certification:

ISO, CE

Graphic Format Supported:

DXF,AI,BMP,PLT,DWG

Cnc Or Not:

Yes

Cooling Mode:

Water Cooling

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Cooling System:

Water Cooling,CW5200 Waterchiller,Industry Water Chiller

Packaging Details:

wood, plastic

Highlight:

automatic vibration bowl feeder

vibration feeder for metal cutting

metal cutting machine feeder bowl

Product Description

QH - Vibratory Bowl Automatic Feeder

Description

The Vibratory Bowl Automatic Feeder is an intelligent precision feeding equipment designed to integrate with laser cutting systems, with its core highlight being the "material sorting certainty"—realized through automatic vibratory feeding, precise orientation, and strong adaptability. It perfectly combines with the "processing precision" of laser cutting (high precision, non-contact processing, multi-material compatibility), forming a full-closed-loop automated precision processing system of "disordered incoming materials → ordered orientation → precise cutting → finished product output". This integrated system is specially developed for large-scale precision processing scenarios such as sheet metal cutting and precision component manufacturing, aiming to achieve efficiency multiplication, precision improvement, flexible production, cost reduction & efficiency enhancement, and intelligent integration, breaking through the limitations of traditional separate feeding and cutting modes that lead to low efficiency and poor precision consistency.

Its "material sorting certainty" is fully reflected in the stable and reliable vibratory feeding, precise orientation, and strong adaptability: the vibratory bowl automatically conveys disordered incoming workpieces, sorts them through intelligent vibration control, and accurately orients each workpiece to the preset position with high consistency, ensuring that every workpiece enters the laser cutting link in a standardized posture—this is the core of its "material sorting certainty", which lays a solid foundation for the subsequent precision cutting. Equipped with a 460mm diameter top bowl, the feeder has a large storage capacity to ensure continuous and stable feeding, avoiding downtime caused by insufficient material supply. It is perfectly matched with laser cutting systems with a laser power range of 1500W-20KW, synchronizing with the 100m/min maximum linkage speed and 1.0G maximum linkage acceleration of the laser cutting machine to achieve seamless connection between feeding and cutting. With a machine weight of 1000kg and overall dimensions of 19680×3958×2560mm, it can be seamlessly integrated into industrial laser cutting production lines, operating at 380V voltage and 50Hz frequency to adapt to standard industrial power supply conditions.

Quick details

Core Highlights: Integrates "material sorting certainty" (automatic vibratory feeding, precise orientation, strong adaptability) with laser cutting "processing precision" (high precision, non-contact, multi-material compatible), forming a full-closed-loop system of "disordered incoming materials → ordered orientation → precise cutting → finished product output"; achieves combined advantages of efficiency multiplication, precision improvement, flexible production, cost reduction & efficiency enhancement, and intelligent integration.

Key Specifications: Top bowl diameter 460mm (large capacity for continuous feeding); machine weight 1000kg; overall dimensions 19680×3958×2560mm (seamless integration with laser cutting lines); laser power compatibility range 1500W-20KW.

Speed & Performance: Synchronizes with 100m/min maximum linkage speed and 1.0G maximum linkage acceleration of laser cutting machines; stable vibratory feeding, precise orientation, no jamming or deviation.

Technical Specifications

Diameter of top bowl	460mm
Machine Weight	1T
Overall Dimensions	1600×1430×1750mm
Laser Power Range	1500W - 20KW
Maximum Linkage Acceleration	1.0G
Maximum Linkage Speed	100m/min
Voltage Requirement	380V
Frequency	50Hz

QH - Vibration Bowl Automatic Feeder 0

Advantage

Synergy of "Material Sorting Certainty" and "Processing Precision", Achieving Precision Leap: The feeder’s "material sorting certainty" ensures that every workpiece is accurately oriented and positioned before cutting, eliminating precision errors caused by irregular workpiece postures in traditional feeding modes. Combined with the laser cutting’s high precision (matched with the feeder’s stable positioning) and non-contact processing, it significantly improves the cutting precision and consistency of finished products, reducing product scrap rate caused by positioning deviation and realizing a leap in processing precision.

Full-Closed-Loop Automated System, Realizing Efficiency Multiplication: The integrated system of "disordered incoming materials → ordered orientation → precise cutting → finished product output" realizes full-process automation without manual intervention, completely replacing manual feeding, sorting and positioning operations. Synchronized with the laser cutting machine’s 100m/min maximum linkage speed, the feeder ensures continuous and efficient feeding, increasing comprehensive production efficiency by 3-5 times compared with traditional manual feeding and cutting modes; the 460mm large-diameter top bowl further ensures uninterrupted production, reducing downtime.

Flexible Production & Strong Adaptability, Meeting Diverse Needs: The feeder’s "material sorting certainty" is supported by strong adaptability, which can flexibly adapt to workpieces of different sizes and materials, matching the laser cutting machine’s multi-material compatibility. It can quickly adjust the orientation parameters according to different workpiece specifications, realizing quick switching between production batches without complicated disassembly and adjustment, thus achieving flexible production and meeting the personalized precision processing needs of enterprises.

Intelligent Integration & Cost Reduction, Creating Long-Term Value: The seamless integration between the feeder and laser cutting systems realizes intelligent linkage of the whole processing process, reducing manual labor costs and human operation errors. The stable performance of the feeder (low maintenance frequency) and the high efficiency of the full-closed-loop system reduce long-term operation costs. Meanwhile, the precision improvement and scrap rate reduction further reduce production costs, achieving the combined advantages of cost reduction, efficiency enhancement and intelligent integration, bringing long-term economic benefits to enterprises.
